This course is designed for signalling staff who will potentially be installing signalling equipment within location cases and trackside equipment.

On successful completion of this course delegates will:

• Demonstrate a good understanding of the Signalling Installation Handbook
• Be capable of constructing the framework for location cases and REB's
• Be capable of cutting and fitting the appropriate ducting to relevant frames
• Understand the importance of using the correct calibrated crimp tools
• Understand the correct termination of wires using the appropriate crimps for the type of wire
• Wire a location case to a signalling diagram and the latest relevant standards
• Be capable of continuity testing a frame to verify the correct termination of wires
• Terminate tail cables and clamp within loc case
• Wire a dis-box to the relevant standard
• Continuity test internal cables within a location case
• Mark up location diagrams in the correct manner
• Complete modifications in a live working location case safely and to the correct standards.

30% Theory based with PowerPoint presentations and active discussions.
70% Practical based building locations to relevant standards.

Delegates are expected to be able to read location diagrams and/or have attended a diagram reading course prior to attending this event.
